Name: Speedfox 02 THREE 29"
Brand: BMC
SKU: BMC-18a-000049-s0070
Availability: OutOfStock

[{"id":40947918143567,"title":"M","option1":"M","option2":null,"option3":null,"sku":"BMC-18a-000049-s0070","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"Speedfox 02 THREE 29\" - M","public_title":"M","options":["M"],"price":0,"weight":0,"compare_at_price":null,"inventory_quantity":0,"inventory_management":"shopify","inventory_policy":"deny","barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":40947918176335,"title":"L","option1":"L","option2":null,"option3":null,"sku":"BMC-18a-000049-s0090","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"Speedfox 02 THREE 29\" - L","public_title":"L","options":["L"],"price":0,"weight":0,"compare_at_price":null,"inventory_quantity":0,"inventory_management":"shopify","inventory_policy":"deny","barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":40947918209103,"title":"XL","option1":"XL","option2":null,"option3":null,"sku":"BMC-18a-000049-s0110","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"Speedfox 02 THREE 29\" - XL","public_title":"XL","options":["XL"],"price":0,"weight":0,"compare_at_price":null,"inventory_quantity":0,"inventory_management":"shopify","inventory_policy":"deny","barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}]

Technische Übersicht

Rahmenset

Rahmen:
Speedfox 02 - Advanced Pivot System - Trailsync | 02 Carbon (F) - Al-13 Triple-butted aluminum (R)

Gabel:
02 Carbon (F) | Al-13 Triple-butted aluminum (R)

Cockpit

Lenker:
BMC MRB 02 | 760mm

Vorbau:
BMC AMSM 02

Sattel

Sattelstütze:
BMC Trailsync | 120mm

Sattel:
WTB Volt Race

Antrieb

Übersetzung:
1 x 11

Kurbel:
RaceFace Aeffect SL 32T

Kassette:
Shimano SLX | 11-46T

Kette:
KMC X-11EL-1

Schaltwerk:
Shimano SLX | Shadow Plus

Schalthebel:
Shimano SLX

Bremsen

Bremshebel:
Shimano SLX (180/180mm)

Räder

Felgen:
DT Swiss M1900 Spline 30

Naben (V/H):
DT Swiss M1900 Spline

Bereifung:
Maxxis Forekaster ExO | 27,5 or 29 x 2.35

Weitere Informationen

Produktsicherheitsverordnung (GPSR):
Sicherheitshinweise GPSR (EU)
Verantwortliche Person gemäss GPSR (EU)

Size	M	L
Reach	430	450
Stack	610	620
Bar Rise	15	15
Bar Sweep	9	9
Bar Width	760	760
BB Drop	37	37
Crank Length	175	175
Fork Length	526	526
Fork Rake	51	51
Front Center	704	728
Head Tube	105	115
Head Tube Angle	68.25	68.25
Rear Center	445	445
Seat Angle	73.25	73.25
Seat Tube	440	480
Stem Length	55	55
Top Tube	611	634
Trail	98	98
Wheelbase	1145	1169
